T43A
-
WhatsApp：https://wa.me/8618694087250
T43A
All-in-one covert hideaway warning/position module, 18.5×18.5×21.57 mm, black bezel, Fresnel optical design, available in single or combination color options. Operating voltage: 10–33 V DC, maximum current: 0.62 A @12V / 0.35 A @24V. Flash patterns: 14. LED quantity: 5W × 1 pcs / strobe: 5W × 1 pcs / position: 0.2W × 2 pcs. Lens material: PC. Mounting: Flush Mount / Tube Flush Mount. Protection: IP67 + 69K. Operating temperature: -30℃ to +70℃. Certified: ECE R10, ECE R65 Class 1 (4 units for a group), R148, SAE J595 Class 2. Warranty: 3 years. Colors: amber, orange, white, red.
contact us
Description
All-in-one covert hideaway warning/position module, 18.5×18.5×21.57 mm, with sleek black bezel.
Fresnel optical system for precise and sharp light output.
Single or combination color configuration available (amber, orange, white, red).
Wide voltage range: 10–33 V DC, current 0.62 A @12V / 0.35 A @24V.
Flash patterns: 14.
LEDs: 5W × 1 pcs / strobe: 5W × 1 pcs / position: 0.2W × 2 pcs.
Durable PC lens with IP67 + 69K protection.
Flexible mounting options: Flush Mount / Tube Flush Mount.
Certified: ECE R10, ECE R65 Class 1 (4 units for a group), R148, SAE J595 Class 2.
Warranty: 3 years.
Fresnel optical system for precise and sharp light output.
Single or combination color configuration available (amber, orange, white, red).
Wide voltage range: 10–33 V DC, current 0.62 A @12V / 0.35 A @24V.
Flash patterns: 14.
LEDs: 5W × 1 pcs / strobe: 5W × 1 pcs / position: 0.2W × 2 pcs.
Durable PC lens with IP67 + 69K protection.
Flexible mounting options: Flush Mount / Tube Flush Mount.
Certified: ECE R10, ECE R65 Class 1 (4 units for a group), R148, SAE J595 Class 2.
Warranty: 3 years.
Specifications
| Product Name | T43A |
|---|---|
| Categories | Covert Hideaway, Modules |
| Dimensions (L×W×H)mm | 18.5*18.5*21.57 |
| Function | Warning/Position Light |
| Bezel Colour | Black |
| Optical | Fresnel |
| Color Type | Single, Combination |
| Operating Voltage | 10-33V DC |
| Maximum Current | 0.62A@12VDC / 0.35A@24VDC |
| Color Modes | Amber, Orange, White, Red |
| Flash Patterns | 14 |
| LED Quantity | 5W*1 pcs / strobe: 5W*1 pcs / position: 0.2W*2 pcs |
| Lens Material | PC |
| Mounting Options | Flush Mount / Tube Flush Mount |
| IP Rating | 67+69K |
| Operating Temperature | -30℃—+70℃ |
| Certifications | ECE R10, ECE R65 Class 1 (4 units for a group), R148, SAE J595 Class 2 |
| Warranty | 3-year |
